Auxiliary equipment - mold labeling machine |
|
|
▲The machine features:
- Computer-controlled CNC machine, can require its own programming.
- Using precision ball screw and linear guides, positioning accuracy.
- X, Y-axis hand wheel fine-tuning operation to facilitate school adjustment.
- Use of dry vacuum pumps, to ensure clean label.
- Multiple machine security.
- Simple and convenient.
- Automatic production.
- Beautifully finished, consistent quality, easy to fall off.
 Product renderings |
Master plan |
▲Mold labeling machineTechnical parameter(Unit: mm):
| Maximum stroke X axis servo motor |
1030 |
Tags center height adjustable |
1185＋－150 |
| Maximum stroke Z-axis servo motor |
200 |
Maximum size label |
400×400 |
| Fastest trip（mm/sec) |
500 |
Minimum size label |
20×20 |
| Machine dimensions (length × width × height) |
1340×1437×1940 |
Weight（KG） |
800 |
|
▲Optional host the main parameters:
Equipment Type |
Screw diameter
mM
|
Plasticizing capacity
kG/H |
Clamping force
KN |
Equipment features |
The largest container producing products |
Can die with the number of
|
Die can be equipped with features |
HFBA45 |
45 |
30 |
24 |
Single-station |
1.8L |
1,2,4 |
S,T |
HFBA55 |
55 |
45 |
38 |
Single-station |
3.5L |
1,2,4 |
S,T,ST |
HFBA65 |
65 |
60 |
56 |
Single-station |
7.5L |
1,2,3,4 |
S,T,ST |
HFBA55R |
55 |
45 |
24 |
Double |
1.8L |
1,2,4 |
S,T,ST |
HFBA65R |
65 |
60 |
38 |
Double |
3.5L |
1,2,3,4 |
S,T,ST |
HFBA75R |
75 |
90 |
56 |
Double |
7.5L |
1,2,3,4 |
S,T,ST |
FT27- |
45/55 |
35/50 |
27 |
Single-station |
1.5L |
1,2,3,4 |
S,T,ST |
FT40- |
55/65 |
50/75 |
40 |
Single-station |
2L |
1,2,3,4,6 |
S,T,ST |
FT70- |
65/75 |
75/105 |
70 |
Single-station |
5L |
1,2,3,4,6 |
S,T,ST |
FT27R- |
55/65 |
50/75 |
27 |
Double |
1.5L |
1,2,3,4 |
S,T,ST |
FT40R- |
65/75 |
75/105 |
40 |
Double |
2L |
1,2,3,4,6 |
S,T,ST |
FT70R- |
75/90 |
105/160 |
70 |
Double |
5L |
1,2,3,4,6 |
S,T,ST |
FT150- |
75/90 |
105/160 |
150 |
Single-station |
10L |
1 |
S,T,ST |
FT150R- |
90/100 |
160/240 |
150 |
Double |
10L |
1 |
S,T,ST |
FT250R- |
90/100 |
160/240 |
250 |
Double |
30L |
1 |
S,T,ST |
Above parameters for reference only, subject to change without notice！ |
|
|
|
|
|
|
 |
